ANTENNA KEY FEATURES
- 19 dBi Directional Gain
- Highest Ingress Protection IP 66
- High Quality Construction
- Horizontal or Vertical Polarization
- Heavy-Duty Mounting Elements
- Easy Elevation and Tilt Adjustment
- 5 Years Warranty
- Designed for All Weather Operation
ANTENNA APPLICATIONS
- 2.4 GHz Band Wireless LAN
- IEEE 802.11b/g WLAN Systems
- Point to Point Application
Meira um net hér
ANTENNA SPECIFICATION
ELECTRICAL PROPERTIES
Frequency range2.4-2.5 GHz
Gain19 dBi
PolarizationLinear. H or V
Beam width horizontal20° @ -3dB
Beam width vertical20° @ -3dB
VSWR<2
Impedance50 ohm
Front to back ratio>35 dB
MECHANICAL PROPERTIES
ConnectorN female
Windload150 km/h
Mounting pole Φ5.5cm / 2.16″
RoHS CompliantYes
ENCLOSURE PROPERTIES
MaterialUV protected PVC
ColourWhite
Outside dimensions348x348x32mm / 13.7×13.7×1.25″
Weight1.26 kg / 2.78 lbs
Temperature range-40 +80°C / -40 +176°F
Lightning protectionDC ground
