Delivers up to 60W of PoE++
Surge, peak pulse, and overcurrent protection
Contains RJ45 data input, AC cable with earth ground, and PoE++ output
LED indicator for status monitoringLýsing
An adapter that can power UniFi PoE++ devices, reduce dependency on PoE switch power, and provide a Multi-Gigabit LAN connection.
Passar fyrir:
Dimensions 106 x 63 x 34 mm (4.2 x 2.5 x 1.3″)
Weight 210 g (7.4 oz)
Output Voltage 54V DC at 1.12A
Rated Voltage 100—240V AC at 50/60Hz
LAN Activity Indicator —
Gigabit LAN Port ✓
Remote Reset Capability —
Reset Button —
4-pair Powering Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
Clamping Protection 11V Data, 60V power
Data In / PoE RJ45 Shielded Socket
Input Current 1.5A Max.
Inrush Current <150A peak at 230V AC
Efficiency >88%
Switching Frequency 65 kHz
Output Ripple 1% Max.
Line Regulation ≤ 2%
Load Regulation ≤ 5%
Max. PoE+ Wattage per Port by PSE 60W
Max. Surge Discharge 1500A (8/20 μs) power
Peak Pulse Current 36A (10/1000 μs) data
Response Time <1 ns
Shunt Capacitance <5 pF data
Surge Protection Difference and common mode
Ambient Storage Temperature -30 to 70°C (-22 to 158° F)
Ambient Operating Temperature 0 to 40° C (32 to 104° F)
Ambient Operating Humidity 10 to 95% noncondensing
NDAA Compliant ✓
Certifications CE, FCC, IC, UL, UKCA, KC, CCC, RoHS
