Lýsing
Góð leið til að koma HDMI merki þráðlaust – sendir fyrir power point sýninguna þína án þess að hafa áhyggjur af hdmi köplunum
Wireless HDMI® Presentation System 10×1, up to 30 m, Full HD 1080p, 5GHz
The wireless HDMI® extender set can be expanded with up to ten extra transmitter units (DS-55307) to turn it into a wireless presentation system.
- Wireless transmission of HDMI® video and audio signals in Full HD to a distance of up to 30 meters in unobstructed areas and up to 20 meters in obstructed areas
- Expand this set with up to ten transmitter units (DS-55307) and turn it into a wireless presentation system
- Up to ten attendees (transmitters) can display their contents on an HDMI® playback device (projector, monitor, TV)
- Change between transmitters quickly and easily at the press of a button to play your contents
- Simply switch the source to be displayed with the press of a button on the transmitter unit – changeover time is approx. 500 ms
- The transmitters can be powered with the HDMI® connection to your device (>500 mAh required), or via the USB connection of your laptop, PC, etc. with the included micro USB cable
- Transmission of HDMI® signals with a maximum resolution of 1080p / 60 Hz
- The transmission distance in obstructed areas cannot be determined generally and depends on the specific environment
- Walls, glass, etc. can cause the signal coverage to be shorter or disrupted
The Wireless HDMI® Extender Set allows wireless transmission of HDMI® video and audio signals over a distance of up to 30 meters in unobstructed areas and up to 20 meters in obstructed areas. Very easy to operate and install. Real Plug & Play – plug in and get started straight away. Additional transmitters (DS-55307) allow the set to be expanded with up to ten additional transmitter units and turned into a wireless presentation system. Up to ten attendees (transmitters) can display their content on an HDMI® playback device (projector, monitor, TV). Change to the desired transmitter quickly and easily just by pressing a button to play your contents. The transmitters can be powered with the HDMI® connection of your device (>500 mAh required), or with the USB connection of your laptop, PC, etc. using the supplied micro USB cable. The receiver is powered with the included power supply. The Wireless HDMI® Extender is the perfect solution for meeting, conference or congress rooms thanks to its additional transmitters.
- Transmission of HDMI® signals with a maximum resolution of 1080p / 60 Hz
- HDMI® version: 1.4
- HDCP: 1.4
- Transmission frequency: 5 GHz
- Transmission delay less than 220 ms
- HDMI® transmission rate: 10.2 Gbps
- Color depth: 8 bit
- LED activity and connectivity indicator
- Display Data Channel (DCC): DCC 1
- Supported audio formats: LPCM
- Power consumption: Transmitter <2.5 W, receiver <6 W
- Power supply receiver: DC 5 V/2 A
- ABS casing
- Operation temperature: 0 – 60°C
- Transmitter dimensions: L 8.9 x W 3.9 x H 1.5 cm
- Receiver dimensions: L 13.8 x W 8.5 x H 1.9 cm
- Transmitter weight: 20 g
- Receiver weight: 120 g
- Color: black
- HDTV Resolution max.: 1920 x 1080 Pixel, 60Hz
- HDTV Standard: Full HD
- Distance: 30 m
- KVM: no
- PoE (Power over Ethernet): no
- USB-C Products: no
- Video connection ports: HDMI
