Optimized for Face ID and Access
G6 Entry prioritizes full person visibility for accurate face identification – delivering the ideal field of view for Face ID.
Field of View: H: 100°, V: 135°, D: 180° Image Size: 5MP, 1920 x 2560 (3:4)
Dimensions 176 x 45 x 29.6 mm (6.9 x 1.8 x 1.2″)
IR Night Vision 5 m (16 ft)
Face Recognition ✓
Smart Detections (People, Vehicles, Animals) ✓
Resolution Main camera: 5MP Package camera: 8MP
Field of View Main camera: H: 100°, V: 135°, D: 180° Package camera: H: 66°, V: 51.7°, D: 78°
Audio Two-way audio
Weatherproofing IP55
Tamper Resistance IK07
Mounting Wall mount, Gangbox mount plate, 20° wedge mount (Included) Junction box (Optional)
NFC Card & Keyfob Access ✓
Apple/Google Wallet ✓
Mobile Unlock ✓
Two-Way Intercom & Doorbell Access ✓
Networking Interface GbE RJ45 port
Connectivity BLE 4.1 NFC
Video
- Image Settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
- Max. Frame Rate Main camera: 30 FPS Package camera: 3 FPS
- Resolution Main camera: 5MP, 1920 x 2560 (3:4) Package camera: 8MP 3264 x 2448 (4:3)
Optics
- Sensor Main camera: 5MP CMOS Package camera: 8MP CMOS
- Lens Fixed focal length
- Night Mode Built-in IR LED illumination and IR cut filter
Max. Power Consumption 16W
Supported Voltage Range 42—57V DC
Power Method PoE+
Processor Quad-core Arm® Cortex®-A53 based chip
Weight 275 g (9.7 oz)
Enclosure Material Aluminum
Mount Material Wall mount: Stainless steel Gangbox mount plate: SGCC steel Gangbox mount cover: Polycarbonate Wedge mount: Aluminum
Button (1) Ring button (1) Factory-reset (1) Tamper switch
LEDs R/G/B/W Learn More
Ambient Operating Temperature -30 to 50° C (-22 to 122° F)
Ambient Operating Humidity 5 to 90% noncondensing
NDAA Compliant ✓
CertificationsCE, FCC, IC
