GIGABIT DIN RAIL SWITCH
Allar upplýsingar hér
ETHERNET
- LAN 5 x RJ45 ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
PERFORMANCE SPECIFICATIONS
- Bandwidth (Non-blocking) 10 Gbps
- Packer buffer 128 KB
- MAC address table size 2K entries
- Jumbo frame support 9216 bytes
POWER
- Connector 2-pin industrial DC power socket
- Input voltage range 9-30 VDC
- PoE (passive) Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
- Power consumption Idle: 0.3 W / Max: 2.3 W
